Product Description

As an efficient waterproof material, geomembrane is widely used in anti-seepage projects in many fields due to its excellent performance. HDPE geomembrane is made of high-density polyethylene as the core material, with ultra-high anti-seepage, extremely strong chemical corrosion resistance (adaptable to strong acid, alkali, oil environment) and resistance to mechanical damage. It is especially suitable for harsh scenes such as landfills, chemical storage tanks and large reservoirs; Geomembrane supports rapid welding construction, has long-term durability (lifespan of more than 50 years) and environmental protection and economy. Through standardized laying and testing, it can significantly improve the efficiency of engineering anti-seepage and reduce environmental risks.

Test		Unit	Standard	Test Frequency	RH75	RH10	RH15	RH20	RH30
Mechanical Properties	Thickness	mm	D5199	per roll	0.75	1.00	1.50	2.00	3.00
	Density	g/cc	D1505/D792	90,000 kg	0.94
	Tensile Properties		D 6693
	· yield strength	kN/m	Type IV	9,000 kg	11	15	22	29	44
	· break strength	kN/m			20	27	40	53	80
	· yield elongation	%			12	12	12	12	12
	· break elongation	%			700	700	700	700	700
	Tear Resistance	N	D 1004	20,000 kg	93	125	187	249	374
	Puncture Resistance	N	D 4833	20,000 kg	240	320	480	640	960
	Stress Crack Resistance	hr.	D 5397	per GRI GM-10	500 hr.
	Carbon Black Content	%	D 4218	9,000 kg	2.0-3.0%
Reference Propertied	Oxidative Induction Time	min	D 3895	90,000 kg	100 min.
	(a) Standard OIT		D 5885		100 min.
	(b) High Pressure OIT				400 min.
	Oven Aging at 85°C retained after 90 days	%	D 5721	per each
	(a) Standard OIT - %		D 3895	formulation	55%
	(b) High Pressure OIT - %		D 5885		80%
	UV Resistance	%		per each
	High Pressure OIT - % retained after 1600 hrs	%	D 5885	formulation	50%
Roll Size	Roll Width	m			7/8	7/8	7/8	7/8	7
Roll Size	Roll Length	m			280	210	140	105	70

Packaging & Dispatch
